EPC · ENERGY, POWER & FILTRATION

Grid-scale power and clean water, engineered and built as one discipline.

EPF Systems designs, procures and constructs utility-scale solar PV, battery energy storage and industrial water infrastructure — wastewater treatment, potable water treatment and desalination — for mines, municipalities, utilities and industry across Southern Africa.

See our project experience → Talk to our engineers
285 MWp
Solar EPC delivered 2023–2024
600+ MLD
Ceramic membrane capacity deployed
7
Engineering disciplines in-house
ISO 9001·14001·45001
Certified management systems
What we build

Two infrastructure disciplines. One EPC team.

Civil, mechanical, electrical, process, control and instrumentation engineers working from the same head office in Gauteng — carrying a project from feasibility layout through construction and commissioning.

01 — Energy

Grid-scale solar & BESS

Utility-scale PV plant design and construction, sub-frame and module installation, electrical single-line design, cable trench and MV works, and containerised battery energy storage integration.

View energy capability →
02 — Water

Water & wastewater treatment

Potable water treatment, municipal and industrial wastewater treatment, desalination and ceramic silicon-carbide membrane filtration — from containerised skids to multi-megalitre plants.

View water capability →
Renewable energy & BESS EPC

Grid-scale solar plant and battery energy storage engineering, procurement & construction

We take utility-scale renewable energy projects from detail design through site establishment, civil and structural construction, module installation, electrical reticulation and grid connection — with battery energy storage integration for firm, dispatchable capacity.

/ 01

Detail design

Plant layout, general arrangement, utility interface and civil/structural detail design for solar farms up to grid scale.

/ 02

Electrical & SCADA

Single-line diagrams, MV cable trench design, communication layouts and equipment general arrangements.

/ 03

Construction

Sub-frame and module installation, foundations, DC/AC trenching and site civil works.

/ 04

BESS integration

Utility-scale liquid-cooled battery module, rack and containerised system specification and integration.

Typical grid-scale delivery chain
PV modules

String-monitored arrays on engineered sub-frame structures

→
Inverter station

DC/AC conversion & string monitoring

→
BESS (optional)

Liquid-cooled battery containers for dispatch & firming

→
Transformer station

MV step-up via prefabricated cable set

→
Substation / grid

33–132 kV facility substation & utility interface

Aerial drone view of a utility-scale solar PV plant
Utility-scale solar PV — aerial view
Technician installing solar sub-frame structures on site
Sub-frame construction & module installation
Close-up of engineered solar sub-frame racking structure
Engineered racking, foundation to module
Cutaway diagram of a containerised liquid-cooled battery energy storage system
Containerised BESS — internal layout
Aerial view of a second utility-scale solar PV plant, De Aar
75 MWp-class solar plant footprint
Utility-scale BESS — representative specification
LevelConfigurationRated energyRated voltageCoolingIP rating
Module2P52S101.84 kWh145.6–187.2 V—IP66
Rack (8 modules)1P52S×8372–407.3 kWh1,331.2 VLiquid coolingBattery room IP56 / control box IP66
Container80 battery modules≈ multi-MWh—Liquid-cooled, water-cooled unit ×1Outdoor-rated

Cells and containers certified to UN38.3, IEC 62619, IEC 62477, UL1973, UL 9540A and NFPA 855.

Water, wastewater & desalination EPC

Potable water treatment, wastewater treatment and desalination plants

From full EPC delivery of desalination plants to containerised, off-grid potable water kiosks, EPF Systems designs and builds water treatment infrastructure for municipalities, mines and industry — and is the Southern African agent for advanced ceramic silicon-carbide membrane filtration technology.

/ 01

Potable water (WTP)

Municipal and rural drinking water treatment from borehole, surface or municipal feed water.

/ 02

Wastewater treatment (WWT)

Municipal and industrial effluent treatment, including COD reduction for process water reuse.

/ 03

Desalination

Full EPC desalination plants and pre-treatment ahead of reverse osmosis for brackish and seawater sources.

/ 04

Decentralised supply

Containerised, plug-and-play, tap-to-pay water dispensing units requiring no external power.

Completed desalination EPC plant tank farm, dusk view
6 MLD desalination EPC — Mozambique
Aerial view of containerised desalination treatment trains under construction
Containerised treatment trains on site
Row of desalination treatment containers at night
Site works, day & night shifts
Chemical dosing hoppers on a water treatment skid
Coagulant dosing skid
Water samples before, during and after industrial COD reduction treatment
Industrial COD reduction — before / during / after
Ceramic membrane technology

Silicon carbide (SiC) ceramic membranes — a shorter, harder-working path to clean water

EPF Systems represents advanced ceramic microfiltration and ultrafiltration membrane technology in Southern Africa: a 0.1-micron mechanical barrier that removes bacteria, algae and suspended solids without chemical or oxygen balancing, and can be backwashed hard without damaging the membrane.

Traditional multi-stage treatment vs. ceramic membrane filtration
Coagulation

Chemical dosing

→
Flocculation

Mixing & settling prep

→
Sedimentation

Settling basin

→
Media / cartridge filter

Sand or cartridge polishing

Coarse screen

Removes gross solids only

→
Coagulation

Minimal dosing, 1–5 mg/l

→
SiC ceramic membrane

0.1 µm mechanical barrier

→
Product water

≈25% of the traditional footprint

Removal performance

  • Suspended solids (TSS): 99% removal
  • Algae: 99% removal
  • Micro-organisms: 99% removal
  • Bacteria: >99% removal
  • Iron & manganese (Fe/Mn): >99% removal
  • Viruses: >90% removal
Ceramic silicon carbide membrane tower submerged for clean water treatment
Ceramic membrane vs. conventional filtration
ParameterUnitCeramic membraneSand filterPolymeric UF
Footprint%2510035
Total suspended solids tolerancemg/l20,0002050
Bacteria removal%>99.9920–50>99.99
Specific energy demandkWh/m³0.020.07–0.180.05
Coagulant dosingmg/l1–520–401–5
Reject / waste water%0.5–55–152–10
500+ installations worldwide 600+ MLD deployed capacity 65 countries 50% drinking water · 35% industrial · 15% municipal wastewater
Performance in the field

Verified results, from raw water to potable and process-ready

Independent laboratory results and operating data from ceramic membrane deployments across drinking water, industrial and municipal applications.

Klipriver · Raw river water

E. coli & faecal coliform removal

Raw water sampled at 600 CFU/100ml E. coli and 4,000 CFU/100ml total coliform. Cholera absent in filtered product across all samples.

E. coli600 → <1 CFU/100ml
Vaal River Barrage

Cholera & turbidity removal

Raw sample tested positive for cholera with a heterotrophic plate count of 42,500 CFU/ml. UV-filtered product tested cholera-absent.

Total coliform290 → <1 CFU/100ml
Sweden · 2016

Groundwater drinking water plant

5.18 MLD groundwater plant at 575 LMH flux and 99% recovery. Membrane autopsy after four years in service showed zero degradation to hardness, strength, integrity or pore size.

Turbidity3.3 → <0.1 NTU
Kingdom of Saudi Arabia · 2021

Pre-RO brackish groundwater

143 MLD deep-well brackish groundwater pre-treatment ahead of reverse osmosis, running at 600–650 LMH flux with 99% recovery.

Iron0.25 → <0.02 mg/l
Alberton · 2023

Industrial process water — COD reduction

Industrial process water with COD above 5,000 mg/l treated for reuse, at a specific energy demand of 0.02 kWh/m³.

COD>5,000 → <2,500 mg/l
Mozambique · Full EPC

6 MLD desalination plant

Complete engineering, procurement and construction of a coastal desalination facility, delivered with full 3D engineering integration from concept through as-built.

Capacity6 MLD
Track record

Selected project experience

Recent solar EPC contracts delivered under EPF Systems, alongside prior utility-scale renewable energy experience carried by our core engineering team.

EPF Systems — recent delivery (2023–2024)

Client / projectScopeSize (MWp)Year
Aurex — SannasposMulti-discipline engineering752024
Aurex — GraspanMulti-discipline engineering752024
Aurex — GrootspruitMulti-discipline engineering752024
Aurex — DwaalboomMulti-discipline engineering502024
Safripol — PV1Site & commissioning assistance, electrical projects (Line 11 Extruder, K0c upgrade, Line 11 Pre-Mixer)102023

Core team experience — prior utility-scale solar delivery

ProjectSize (MWp)
Kalkbulk — detail design & construction75
De Aar solar PV project75
Utility-scale solar PV project90
Utility-scale solar PV project82
Utility-scale solar PV project30
Utility-scale solar PV project28
Sasolburg solar PV project10

Prior experience delivered under a different corporate structure, carried forward by the same core engineering and delivery team now at EPF Systems.

Broader EPC & industrial pedigree

Mining

Coal process plant

Full 3D-engineered process plant integration for coal beneficiation.

Mining

Diamond process plant

Structural steel and process plant design, Red Area.

Petroleum infrastructure

NMPP terminal, Durban & Heidelberg

Tank farm and terminal 3D engineering.

Company

A multi-disciplinary EPC team under one roof

EPF Systems is a multi-disciplinary engineering, procurement and construction company headquartered in Gauteng, specialising in energy, pumping and filtration solutions throughout Southern Africa. Our engineering compliment covers every discipline a grid-scale energy or water project needs — in-house.

Incorporated in 2014, EPF Systems grew its engineering bench substantially in 2021 when the South African engineering complement of Kentz Engineers & Constructors joined the group following SNC-Lavalin's exit from South Africa. Today that heritage gives EPF Systems and its group companies over 630 man-years of combined multi-disciplinary engineering experience delivering projects for blue-chip clients across the region.

CIVIL

Civil & architecture

Site layout, structural civils, buildings and access infrastructure.

MECH

Mechanical & structural

Plant structures, process mechanical design and steel detailing.

PROCESS

Process engineering

Water, filtration and industrial process flow design.

E&I

Electrical, control & instrumentation

Single-line design, SCADA, control philosophy and field instrumentation.

ISO 9001:2015

Quality management — consistent delivery of projects, products and services against customer and regulatory requirements.

ISO 14001:2015

Environmental management — responsible, accountable operation in the environments we work in.

ISO 45001:2018

Occupational health & safety — preventing work-related injury and ill health while continually improving OH&S performance.

Planning a grid-scale energy or water treatment project?

Request our capability statement →
